Electric Hydraulic Box Dumpers
Our Electric Hydraulic Box Dumpers are designed for controlled dumping of material from boxes, crates and many other types of containers. Lowered height of only 3/8" allows for pallet truck loading and unloading. Retaining bar for use with 24", 30" and 36" high containers (contact factory for other hold-down bar heights). Maximum dump angle is 45°. Chute reach is 10". Internal 2HP power unit and hand held control standard. Protective mesh side screens included. Heavy-duty welded steel construction. Painted blue finish.
Features:
| * Welding to meet American Welding Society standards | * 24 Volt, fused control circuit to protect operator. |
| * Hydraulic Actuators have internal safety velocity fuse w/stainless steel spring for emergency lockup | * Voltage - 208-230/460 Volt, 60 cycle, 3 phase |
| * Industrial quality, 56 frame, 2 HP motor delivers best torque with minimal amperage draw and maximum life. | |
| * Cast iron pump with integral valving including pressure relief valve, check valve, down solenoid valve and pressure compensated flow control valve. | |
This ergonomic material handling equipment can help your facility increase employee productivity and decrease the risk of injury due to bending and lifting!
**All measurements in the table are represented in inches, pounds and $USD.
| Electric Hydraulic Box Dumpers | |||||||||||
| Model # | Dump Height | Level Height | Rotated Height | Usable Chute | Hold Downs | Capacity | Overall Size | Weight | Price | ||
| W | L | W | L | ||||||||
| HBD-2-36 | 36 | 53 1/2 | 111 | 52 | 50 | 18" - 36" | 2,000 | 69 | 68 1/2 | 1,615 | $7,118.00 |
| HBD-2-48 | 48 | 65 | 129 1/2 | 52 | 50 | 18" - 42" | 2,000 | 69 | 68 1/2 | 1,766 | $8,095.00 |
| HBD-2-60 | 60 | 77 | 149 1/2 | 52 | 50 | 18" - 50" | 2,000 | 69 | 68 1/2 | 1,934 | $8,733.00 |
| HBD-4-36 | 36 | 53 1/2 | 111 | 52 | 50 | 18" - 36" | 4,000 | 69 | 68 1/2 | 1,639 | $8,778.00 |
| HBD-4-48 | 48 | 65 | 129 1/2 | 52 | 50 | 18" - 42" | 4,000 | 69 | 68 1/2 | 1,844 | $9,055.00 |
| HBD-4-60 | 60 | 77 | 149 1/2 | 52 | 50 | 18" - 50" | 4,000 | 69 | 68 1/2 | 2,005 | $9,662.00 |
| HBD-6-36 | 36 | 53 1/2 | 111 | 52 | 50 | 18" - 36" | 6,000 | 69 | 68 1/2 | 1,804 | $9,238.00 |
| HBD-6-48 | 48 | 65 | 129 1/2 | 52 | 50 | 18" - 42" | 6,000 | 69 | 68 1/2 | 1,984 | $9,473.00 |
| HBD-6-60 | 60 | 77 | 149 1/2 | 52 | 50 | 18" - 50" | 6,000 | 69 | 68 1/2 | 2,089 | $10,152.00 |
Fabrication Authorities International also has the knowledge and experience to provide custom designs and options. Our years of manufacturing expertise will ensure that our manufacturing methods meet your application needs and your quality expectations. This combined industry experience and flexibility will provide the correct ergonomic solution for your unique application.
We are dedicated to providing solutions for all of your access needs. Contact us for a professional consultation with our sales technicians today. All of our products may be modified or completely custom designed to suit your needs. Our dedicated staff can assist you from concept to completion in a timely fashion.
Please call for additional options or custom designs.
Fabrication Authorities International, LLC. Is your new “total access” solution.
We can customize most Industrial Maintenance Platforms to your specific needs.
Please call (877) 324-9990 or (727) 324-4620 or (727) FAI-INC-0
Fax us your request at (888) 909-6780
Email us at sales@industrial-platforms.com
If you are looking for a custom product, please include the model number closest to what you need, along with your custom requirements!
For a complete quote including freight, include your shipping address or zip code. Freight quotes are valid for 30 days
