Electric Hydraulic Lift and Tilt Scissor Tables
Our Electric Hydraulic Lift and Tilt Scissor Tables perform both lifting and tilting operations. Features a 45° tilt standard. Restraining chain and a 12" high lip keep load in place during tilting. End tilt standard, side tilt available. Optional accordion skirting available for both the lifting and tilting portions of the table, contact factory for pricing.
Safety features include:
Electric toe guard to shield workers from pinch points during lowering of table, velocity fuses to stop travel due to loss of hydraulic pressure, a 4 push-button hand pendent control on an 8 foot coil cord, and an upper limit switch to stop travel at maximum height, thereby reducing motor wear and maintenance prop.
Features:
| * 3000 PSI component rating on crimped hoses and fittings | * Fused 24 Volt control helps to ensure operator safety |
| * Industrial quality, 56 frame, 2 HP motor delivers best torque | * 45 degree maximum tilt, 36" of vertical travel |
| * NEMA-4 hand control provides a weatherproof case for years of durability | * Upper Travel limit switch is field adjustable |
| * Unique link tilt design center of load remains closer to the center of the table | * Perimeter pinch point guard |
| * Steel Cradle is 12" high, open design allows loading/unloading from three sides | * Slot lock and restraint chain |
| * Safety Velocity fuse in cylinder prevents drop of table in event of hydraulic failure | |
| Electric Hydraulic Lift and Tilt Scissor Tables | |||||||||
| Model # | Platform Size | Uniform Capacity | Height | Overall Size | Weight | Price | |||
| W | L | Raised | Lowered | W | L | ||||
| 45° End Tilt | |||||||||
| EHLTT-3648-1-47 | 36 | 48 | 1,000 | 47 | 11 | 36 | 56 | 1,147 | $6,882.00 |
| EHLTT-4848-1-47 | 48 | 48 | 1,000 | 47 | 11 | 48 | 56 | 1,207 | $7,103.00 |
| EHLTT-3648-2-47 | 36 | 48 | 2,000 | 47 | 11 | 36 | 56 | 1,147 | $6,947.00 |
| EHLTT-4848-2-47 | 48 | 48 | 2,000 | 47 | 11 | 48 | 56 | 1,207 | $7,205.00 |
| EHLTT-3648-3-47 | 36 | 48 | 3,000 | 47 | 11 | 36 | 56 | 1,147 | $7,917.00 |
| EHLTT-4848-3-47 | 48 | 48 | 3,000 | 47 | 11 | 48 | 56 | 1,207 | $8,347.00 |
| EHLTT-3648-4-47 | 36 | 48 | 4,000 | 47 | 11 | 36 | 56 | 1,148 | $8,882.00 |
| EHLTT-4848-4-47 | 48 | 48 | 4,000 | 47 | 11 | 48 | 56 | 1,149 | $9,494.00 |
| EHLTT-4848-5-47 | 48 | 48 | 5,000 | 49 | 13 | 48 | 56 | 1,502 | $11,764.00 |
| 45° Side Link Tilt | |||||||||
| EHLTTS-3654-2-48 | 36 | 54 | 2,000 | 48 | 12 | 38 | 54 | 1,127 | $7,440.00 |
| EHLTTS-3654-4-48 | 36 | 54 | 4,000 | 48 | 12 | 38 | 54 | 1,165 | $9,256.00 |
| 90° Hinge Tilt | |||||||||
| EHLTT-H-3648-2-47 | 36 | 48 | 2,000 | 47 | 11¼ | 36 | 57 | 1,055 | $7,361.00 |
| EHLTT-H-4848-2-47 | 48 | 48 | 2,000 | 47 | 11¼ | 48 | 57 | 1,268 | $7,665.00 |
Options & Accessories:
| Options & Accessories | |||
| Model # | Description | Weight | Price |
| RRC-2PB | 2 Button Wireless Remote | 1 | $1,394.00 |
| RRC-4PB | 4 Button Wireless Remote | 1 | $1,394.00 |
| ROTATE | Manual built-in carousel | n/a | $1,296.00 |
| FC-4 | Four pedal foot control | n/a | $351.00 |
| PROGRAM | Programmable height | n/a | $2,096.00 |
| EHLTT-ROTARY-WMPB | Air/oil power with pneumatic push button | 36 | $4,579.00 |
Fabrication Authorities International also has the knowledge and experience to provide custom designs and options. Our years of manufacturing expertise will ensure that our manufacturing methods meet your application needs and your quality expectations. This combined industry experience and flexibility will provide the correct ergonomic solution for your unique application.
We are dedicated to providing solutions for all of your access needs. Contact us for a professional consultation with our sales technicians today. All of our products may be modified or completely custom designed to suit your needs. Our dedicated staff can assist you from concept to completion in a timely fashion.
Please call for additional options or custom designs.
Fabrication Authorities International, LLC. Is your new “total access” solution.
We can customize most Industrial Maintenance Platforms to your specific needs.
Please call (877) 324-9990 or (727) 324-4620 or (727) FAI-INC-0
Email us at sales@industrial-platforms.com
If you are looking for a custom product, please include the model number closest to what you need, along with your custom requirements!
For a complete quote including freight, include your shipping address or zip code. Freight quotes are valid for 30 days
