Fixed Vertical and Cage Ladders (FV & FC Series) These Fixed Vertical and Cage Ladders are designed for use where safe, solid, vertical climbing access is required with safety cage protection. Our fixed cage ladders meet or exceed OSHA & ANSI standards. Designed specifically for roof and platform access, our fixed cage and vertical ladders meet all known building codes and have a standard 300 lbs. capacity. Features: • Carbon steel heavy duty construction • 300 lbs. capacity • 18"W Traction treads • Ships all-welded • OSHA and ANSI compliant design • Cage flared at bottom • Medium gray enamel paint • 1" Diameter wall . . .
Fixed Vertical and Cage Ladders (FV & FC Series)
These Fixed Vertical and Cage Ladders are designed for use where safe, solid, vertical climbing access is required with safety cage protection. Our fixed cage ladders meet or exceed OSHA & ANSI standards. Designed specifically for roof and platform access, our fixed cage and vertical ladders meet all known building codes and have a standard 300 lbs. capacity.
Features:
| • Carbon steel heavy duty construction | • 300 lbs. capacity |
| • 18"W Traction treads | • Ships all-welded |
| • OSHA and ANSI compliant design | • Cage flared at bottom |
| • Medium gray enamel paint | • 1" Diameter wall rungs |
| • Cage begins seven feet from ground | • Handrail extending 42 inches above the top rung |
Fabrication Authorities International, LLC. designs and manufactures fixed caged ladders to comply with OSHA 1910.27 and 1910.24 and ANSI A14.3 standards. We are equipped to meet your specialty needs for rooftops, mezzanines, storage tanks, industrial equipment access, or any other arena.
**All measurements in the table below are represented in inches, pounds and $USD.
| Fixed Vertical Ladders - With Cage | ||||
| Model # | # Rungs | Overall Length | Weight | Price |
| MFC10 | 10 | 152" | 187 | $1,240.00 |
| MFC12 | 12 | 176" | 223 | $1,431.00 |
| MFC14 | 14 | 200" | 261 | $1,660.00 |
| MFC16 | 16 | 224" | 299 | $1,958.00 |
| MFC18 | 18 | 248" | 338 | $2,197.00 |
| MFC20 | 20 | 272" | 368 | $2,343.00 |
| MFC22 | 22 | 296" | 405 | $3,227.00 |
| MFC24 | 24 | 320" | 442 | $3,449.00 |
| Fixed Vertical Ladders - Without Cage | ||||
| MFV10 | 10 | 152" | 124 | $706.00 |
| MFV12 | 12 | 176" | 142 | $805.00 |
| MFV14 | 14 | 200" | 161 | $905.00 |
| MFV16 | 16 | 224" | 181 | $1,026.00 |
| MFV18 | 18 | 248" | 194 | $1,115.00 |
| MFV20 | 20 | 272" | 223 | $1,214.00 |
Offering the flexibility of a ladder, but with the reliability and reassurance of a stair, a fixed ladder is an excellent option for facilities with limited space. We can design and manufacture any fixed ladder and stairway built according to your specifications based on your environment and application requirements. Our expertise includes in-house research and development, fully integrated manufacturing and an extensive materials line. With years of design, engineering and manufacturing experience, our dedicated staff can assist you from concept to completion in a timely fashion.
Please call for additional options or custom designs.
Fabrication Authorities International, LLC. Is your new “total access” solution.
We can customize most Industrial Maintenance Platforms to your specific needs.
Please call (877) 324-9990 or (727) 324-4620 or (727) FAI-INC-0
Fax us your request at (888) 909-6780
Email us at sales@industrial-platforms.com
If you are looking for a custom product, please include the model number closest to what you need, along with your custom requirements!
For a complete quote including freight, include your shipping address or zip code. Freight quotes are valid for 30 days
