Steel Safety Rolling Ladder - Assembled
Steel Safety Rolling Ladder - Assembled
Steel Safety Rolling Ladder - "Set Up" Model Safety is foremost for the design of our Steel Safety Rolling Ladders. With easy climbing angles, sturdy handrails, and large steps and platform manufactured from slip resistant expanded metal, these ladders help to boost production, while reducing hazards on the job. The caster assemblies are designed to secure the ladder to the floor when in use, and to permit easy rolling from job to job. Features: • 10"D Top platform standard • 20"D and 30"D available! • 450 lbs. capacity • 59-degree industrial slope • 16", 24", or 30"W Treads • Manufactured with rigid 1" OD tubing • Foot activated safe lock (5 steps and larger) • 30" o. . .
Steel Safety Rolling Ladder - "Set Up" Model
Safety is foremost for the design of our Steel Safety Rolling Ladders. With easy climbing angles, sturdy handrails, and large steps and platform manufactured from slip resistant expanded metal, these ladders help to boost production, while reducing hazards on the job. The caster assemblies are designed to secure the ladder to the floor when in use, and to permit easy rolling from job to job.
Features:
| • 10"D Top platform standard | • 20"D and 30"D available! |
| • 450 lbs. capacity | • 59-degree industrial slope |
| • 16", 24", or 30"W Treads | • Manufactured with rigid 1" OD tubing |
| • Foot activated safe lock (5 steps and larger) | • 30" or 42" handrails; depending on platform height |
| • Standard finish is powder coat grey | • Built to OSHA and ANSI standards |
| • Perforated tread standard - others available! | • Cal-OSHA available upon request |
Options:
| Options | ||
| Option | Price | Add After Model # |
| Platform Options | ||
| 20"D Platform (Steps 1-5) | add $180.00 to ladder cost | E20 |
| 20"D platform (6-16 steps) | add $241.00 to ladder cost | E20 |
| 30"D platform (1-5 steps) | add $300.00 to ladder cost | E30 |
| 30"D platform (6-16 steps) | add $366.00 to ladder cost | E30 |
| Tread Options | ||
| Grip strut (Serrated) - Heavy duty, most rugged tread, self cleaning | add 30% of ladder cost | A2 |
| Rubber Tread - Solid metal with non slip rubber tread (For office use). | add 20% of ladder cost | A3 |
| Misc. Options | ||
| Folding Work shelf - 10"D and wide as ladder ordered. Fixed or folding, hardware included | add $135.00 to ladder cost | G1 |
| Wire Basket - Removable 12"W x 18"L x 5"D wire basket with hooks | add $318.00 to ladder cost | F1 |
**All measurements in the table below are represented in inches, pounds and $USD.
| Steel Safety Rolling Ladders | |||||||
| # Steps | Height | Base Size | Weight | 1000 Series | |||
| Platform | Overall | W | L | Model # | Price | ||
| 16"W Treads x 10"D Platform | |||||||
| 1* | 12 | 12 | 18 | 16 | 18 | *1001N1818 | $269.00 |
| 1 | 12 | 16 | 18 | 16 | 19 | 1001G1818 | $275.00 |
| 2* | 20 | 20 | 18 | 19 | 25 | *1002N1818 | $300.00 |
| 2 | 20 | 50 | 18 | 19 | 37 | 1002R1818 | $363.00 |
| 3* | 30 | 30 | 20 | 26 | 31 | *1003N1820 | $367.00 |
| 3 | 30 | 60 | 20 | 26 | 43 | 1003R1820 | $395.00 |
| 4* | 40 | 40 | 20 | 31 | 45 | *1004N1820 | $415.00 |
| 4 | 40 | 70 | 20 | 31 | 53 | 1004R1820 | $462.00 |
| 5 | 50 | 80 | 20 | 40 | 81 | 1005R1820 | $608.00 |
| 6 | 60 | 90 | 24 | 46 | 95 | 1006R1824 | $800.00 |
| 7 | 70 | 100 | 24 | 53 | 105 | 1007R1824 | $827.00 |
| 8 | 80 | 110 | 24 | 61 | 131 | 1008R1824 | $1,057.00 |
| 9 | 90 | 120 | 24 | 67 | 143 | 1009R1824 | $1,132.00 |
| 24"W Treads x 10"D Platform | |||||||
| 1* | 12 | 12 | 26 | 16 | 29 | *1001N2626 | $276.00 |
| 1 | 12 | 16 | 26 | 16 | 26 | 1001G2626 | $292.00 |
| 2* | 20 | 20 | 26 | 19 | 29 | *1002N2626 | $327.00 |
| 2 | 20 | 50 | 26 | 19 | 36 | 1002R2626 | $385.00 |
| 3* | 30 | 30 | 30 | 26 | 42 | *1003N2630 | $394.00 |
| 3 | 30 | 60 | 30 | 26 | 50 | 1003R2630 | $438.00 |
| 4* | 40 | 40 | 30 | 31 | 53 | *1004N2630 | $462.00 |
| 4 | 40 | 70 | 30 | 31 | 61 | 1004R2630 | $508.00 |
| 5 | 50 | 80 | 30 | 40 | 97 | 1005R2630 | $705.00 |
| 6 | 60 | 90 | 30 | 46 | 109 | 1006R2630 | $865.00 |
| 7 | 70 | 100 | 30 | 53 | 121 | 1007R2630 | $931.00 |
| 8 | 80 | 110 | 32 | 61 | 154 | 1008R2632 | $1,211.00 |
| 9 | 90 | 120 | 32 | 67 | 166 | 1009R2632 | $1,301.00 |
| 10 | 100 | 130 | 32 | 74 | 179 | 1010R2632 | $1,433.00 |
| 11 | 110 | 140 | 32 | 81 | 191 | 1011R2632 | $1,472.00 |
| 12 | 120 | 162 | 32 | 88 | 215 | 1012R2632 | $1,607.00 |
| 30"W Treads x 10"D Platform | |||||||
| 4* | 40 | 40 | 32 | 31 | 66 | *1004N3232 | $608.00 |
| 4 | 40 | 70 | 32 | 31 | 74 | 1004R3232 | $735.00 |
| 5 | 50 | 80 | 32 | 40 | 113 | 1005R3232 | $825.00 |
| 6 | 60 | 90 | 32 | 46 | 128 | 1006R3232 | $1,081.00 |
| 7 | 70 | 100 | 32 | 53 | 143 | 1007R3232 | $1,172.00 |
| 8 | 80 | 110 | 32 | 61 | 179 | 1008R3232 | $1,370.00 |
| 9 | 90 | 120 | 32 | 67 | 195 | 1009R3232 | $1,462.00 |
| 10 | 100 | 130 | 32 | 74 | 211 | 1010R3232 | $1,650.00 |
| 11 | 110 | 140 | 32 | 81 | 226 | 1011R3232 | $1,808.00 |
* Indicated models with NO handrails
Industrial rolling safety ladders are our specialty. We offer hundreds to choose from, with a vast range of materials, heights and styles. Don’t see what you need? We have the knowledge and experience to design and manufacture a completely custom rolling ladder for any industry or application. Contact our experienced sales team for a professional consultation and we can custom design a ladder to fit your facility’s needs and space requirements.
Please call for additional options or custom designs.
Fabrication Authorities International, LLC. Is your new “total access” solution.
We can customize most Industrial Maintenance Platforms to your specific needs.
Please call (877) 324-9990 or (727) 324-4620 or (727) FAI-INC-0
Email us at sales@industrial-platforms.com
If you are looking for a custom product, please include the model number closest to what you need, along with your custom requirements!
For a complete quote including freight, include your shipping address or zip code. Freight quotes are valid for 30 days
